Technical Data:
Outer Diameter: 93 MM
Thread Size: 13/16-16 UN
Length: 138 MM
Gasket OD: 71 MM
Gasket ID: 62 MM
Efficiency 99%: 40 MICRON
Efficiency Test Std: SAE J1858
Bypass Valve: Yes
Bypass Valve Setting LR: 0.6 BAR
Bypass Valve Setting HR: 0.7 BAR
Media Type: Cellulose
Collapse Burst: 6.9 BAR
Type: Full-Flow
Style: Spin-On
Accessories:
| 1 | EUCLID - 170200 (P550188) |
| 1 | EUCLID - 4041959 (P550188) |
| 1 | EUCLID - 6437852 (P550188) |
| 1 | FILT - FF2001EC (P550188) |
| 1 | FORD - 9576P550188 (P550188) |
| 1 | FSA - FO1002 (P550188) |
| 1 | FISPA - FOE173 (P550188) |
| 1 | AMERICAN PARTS - 624 (P550188) |
| 1 | AMERICAN PARTS - 92581 (P550188) |
| 1 | GOULD - P351 (P550188) |
| 1 | HAVAM - HD0188 (P550188) |
| 1 | JOHN DEERE - 170200 (P550188) |
| 1 | KNECHT - AW41 (P550188) |
| 1 | KOMATSU - 170200 (P550188) |
| 1 | KOMATSU - 6685819910 (P550188) |
| 1 | KOMATSU - VC8813 (P550188) |
| 1 | KENWORTH - KW632B (P550188) |
| 1 | LETOURNEAU - 170200 (P550188) |
| 1 | LETOURNEAU - BC8813 (P550188) |
| 1 | LETOURNEAU - VC8813 (P550188) |
| 1 | LIMA - 170200 (P550188) |
| 1 | LOCKHEED - AP3233A (P550188) |
| 1 | AC DELCO - PF27 (P550188) |
| 1 | ORENSTEIN & KOPPEL - 103841 (P550188) |
| 1 | PERRY - PL198 (P550188) |
| 1 | P & H - 1046Z72 (P550188) |
| 1 | PETTIBONE - 170200 (P550188) |
| 1 | PUROLATOR - 6667028 (P550188) |
| 1 | PUROLATOR - L30026 (P550188) |
| 1 | PUROLATOR - PER26 (P550188) |
| 1 | RENAULT VI - 6005019770 (P550188) |
| 1 | SOPARIS - CV337 (P550188) |
| 1 | STAY READY - SRP499 (P550188) |
| 1 | SAVARA - 92818417 (P550188) |
| 1 | TEREX - 103841 (P550188) |
| 1 | TEREX - 6437852 (P550188) |
| 1 | TROJAN - 170200 (P550188) |
| 1 | UFI - 2311201 (P550188) |
| 1 | BIG A - 92581 (P550188) |
| 1 | VOLVO - 818511 (P550188) |
| 1 | VMC - LF550188 (P550188) |
| 1 | VERSATILE - 170200 (P550188) |
| 1 | WABCO - BC8813 (P550188) |
| 1 | WABCO - VC8813 (P550188) |
| 1 | WGB - S265CP (P550188) |
| 1 | WHITE - 892575 (P550188) |
| 1 | WHITE - 892575A (P550188) |
| 1 | WORTHINGTON - 170200 (P550188) |
| 1 | BOSCH-REXROTH - 451104005 (P550188) |
| 1 | BOSCH-REXROTH - 8014H (P550188) |
| 1 | BOSCH-REXROTH - 9457280140 (P550188) |
| 1 | BUFFALO-SPRINGFIELD - 170200 (P550188) |
| 1 | CATERPILLAR - 3I1617 (P550188) |
| 1 | CHAMP - FP1524998 (P550188) |
| 1 | CHAMP - FP152499B (P550188) |
| 1 | CHICAGO PNEUMATIC - 170200 (P550188) |
| 1 | CLARK,J.L. - 152499 (P550188) |
| 1 | CLARK,J.L. - 892575A (P550188) |
| 1 | CLARK - 152499 (P550188) |
| 1 | CLARK - 170200 (P550188) |
| 1 | CLARK - 892575 (P550188) |
| 1 | CLARK - 892575A (P550188) |
| 1 | COLES-GROVE - 741195 (P550188) |
| 1 | COOP - PL632 (P550188) |
| 1 | CONSOLIDATED PNEUMATIC - 170200 (P550188) |
| 1 | COOPERS - AZL058 (P550188) |
| 1 | COOPERS - LSF5055 (P550188) |
| 1 | CRANE CARRIER - 170200 (P550188) |
| 1 | CUMMINS - 152499 (P550188) |
| 1 | CUMMINS - 170200 (P550188) |
| 1 | CUMMINS - 253243 (P550188) |
| 1 | CUMMINS - BM75654 (P550188) |
| 1 | CUMMINS - CL632B (P550188) |
| 1 | CYCLONE - PM351 (P550188) |
| 1 | DELUXE - 423 (P550188) |
| 1 | DELUXE - WD423 (P550188) |
| 1 | FLEETRITE - LFR8632B (P550188) |
| 1 | FRAM - PH37 (P550188) |
| 1 | FLEETGUARD - LF632B (P550188) |
| 1 | HASTINGS - LF129 (P550188) |
| 1 | HASTINGS - P129 (P550188) |
| 1 | LUBER-FINER - LFP152499B (P550188) |
| 1 | LUBER-FINER - LFP15499B (P550188) |
| 1 | MOTORCRAFT - FL234 (P550188) |
| 1 | MICROPORE - PHM37 (P550188) |
| 1 | MAHLE - AW41 (P550188) |
| 1 | NAPA - 1581 (P550188) |
| 1 | BALDWIN - BT112 (P550188) |
| 1 | RYCO - Z32 (P550188) |
| 1 | SAKURA - C8031 (P550188) |
| 1 | SF-FILTER - SO1321 (P550188) |
| 1 | WOODGATE - WGL632 (P550188) |
| 1 | WIX - 51581 (P550188) |
| 1 | WIX - CW581MP (P550188) |
| 1 | HIFI FILTER / JURA FILTRATION - SO632 (P550188) |
| 1 | CHAMPION LABORATORIES - FP152499B (P550188) |
| 1 | CARQUEST - 85581 (P550188) |
