Technical Data:
Inlet Diameter: 153.39 MM
Outlet Diameter: 153.39 MM
Body Diameter Minimum: 254 MM
Body Diameter Maximum: 381 MM
Body Length: 806.45 MM
Overall Length: 1079.5 MM
Rated Flow LR: 61.1 CMM
Rated Flow MR: 86.4 CMM
Rated Flow HR: 105.8 CMM
Back Pressure Low-Range: 25 MM HG
Back Pressure Mid-Range: 51 MM HG
Back Pressure High-Range: 76 MM HG
Attenuation LR: 10 DBA
Attenuation HR: 15 DBA
Inlet Clock Position: 3:00
Outlet Clock Position: 9:00
Style: Style 2
Accessories:
| 1 | EUCLID - E12651880 (M122300) |
| 1 | EIMCO - 9283113008 (M122300) |
| 1 | FREIGHTLINER - DNM122300 (M122300) |
| 1 | HEAVY DUTY MFG - 31197 (M122300) |
| 1 | A P PARTS - 3646 (M122300) |
| 1 | A P PARTS - 3646Q (M122300) |
| 1 | INGERSOLL RAND - 22139455 (M122300) |
| 1 | INGERSOLL RAND - 22139544 (M122300) |
| 1 | INGERSOLL RAND - 22139555 (M122300) |
| 1 | INGERSOLL RAND - 911753 (M122300) |
| 1 | ASTEC UNDERGROUND - 3010305004 (M122300) |
| 1 | LEROI - GD202SPT063 (M122300) |
| 1 | ATLAS COPCO - 5540175500 (M122300) |
| 1 | MORBARK - 29323095 (M122300) |
| 1 | INTERNATIONAL - DCM122300 (M122300) |
| 1 | NELSON - 86180M (M122300) |
| 1 | PIVOT POWER INC - 44M122300 (M122300) |
| 1 | RIMPULL - 225039 (M122300) |
| 1 | RIKER - 15913 (M122300) |
| 1 | SCHRAMM - 01290055 (M122300) |
| 1 | SCHRAMM - 1290055 (M122300) |
| 1 | SANDVIK - 001487001 (M122300) |
| 1 | STEMCO - 1901348 (M122300) |
| 1 | TAMROCK - 001487001 (M122300) |
| 1 | TRUCKEX - 3913 (M122300) |
| 1 | WAGNER MINING EQUIPMENT - 5540175500 (M122300) |
| 1 | WALKER MANUFACTURING - 22907 (M122300) |
| 1 | CMI - 004003012000 (M122300) |
| 1 | CMI - 4003012000 (M122300) |
| 1 | CMI - 43012 (M122300) |
| 1 | DRILTECH - 001487001 (M122300) |
| 1 | DRILTECH - 1487001 (M122300) |
| 1 | GRAND ROCK - M180 (M122300) |
| 1 | PARTS DISTRIBUTING - 11197 (M122300) |
