Technical Data:
Length: 650 MM
Inlet Diameter: 203 MM
Outlet Diameter: 203 MM
Body Diameter Maximum: 457 MM
Body Length: 563 MM
Overall Length: 735 MM
Inlet Length: 290 MM
Outlet Length: 85 MM
Service Clearance: 727 MM
Rated Flow LR: 34.6 CMM
Rated Flow MR: 40.2 CMM
Rated Flow HR: 45.3 CMM
Restriction LR: 152 MM H2O
Restriction MR: 203 MM H2O
Restriction HR: 254 MM H2O
Style: Radialseal
Family: FRG
Brand: RadialSeal™
Vacuator Clearance: 401 MM
Inlet Location: 128 MM
Accessories:
VACUATOR VALVE
COUVERCLE FRG18
ELEMENT
ELEMENT
| 1 | KUHN AUDUREAU - A7120010 (G180073) |
| 1 | ATLAS COPCO - 1606241300 (G180073) |
| 1 | ATLAS COPCO - 1606663501 (G180073) |
| 1 | MTU - X00020441 (G180073) |
| 1 | MTU - X57512100002 (G180073) |
| 1 | NEUSON - 1000182577 (G180073) |
| 1 | SDMO - 30801086201 (G180073) |
| 1 | SOILMEC - 40040019 (G180073) |
| 1 | SANDVIK - 504771 (G180073) |
| 1 | TAMROCK - 504771 (G180073) |
| 1 | AGCO - 6237220M91 (G180073) |
| 1 | DONALDSON - FRG180073 (G180073) |
