Technical Data:
Inlet Diameter: 177.8 MM
Outlet Diameter: 177.8 MM
Body Diameter Maximum: 279.4 MM
Body Length: 692.15 MM
Overall Length: 769.6 MM
Rated Flow LR: 34 CMM
Rated Flow MR: 39.6 CMM
Rated Flow HR: 45.3 CMM
Restriction LR: 152 MM H2O
Restriction MR: 203 MM H2O
Restriction HR: 254 MM H2O
Family: ECG
Accessories:
ELEMENT
| 1 | KENWORTH - ECG112501 (G112501) |
| 1 | ASTEC UNDERGROUND - AU118124 (G112501) |
| 1 | ONAN - 01402463 (G112501) |
| 1 | ONAN - 1402463 (G112501) |
| 1 | DART - ECG112501 (G112501) |
