Technical Data:
Inlet Diameter: 76 MM
Outlet Diameter: 76 MM
Body Diameter Maximum: 182 MM
Body Length: 330 MM
Overall Length: 375.2 MM
Rated Flow LR: 2.8 CMM
Rated Flow MR: 4.1 CMM
Rated Flow HR: 5.2 CMM
Restriction LR: 100 MM H2O
Restriction MR: 200 MM H2O
Restriction HR: 300 MM H2O
Style: Radialseal
Family: FPG
Brand: RadialSeal™
Primary Application: TEREX 2479829
Accessories:
VACUATOR VALVE FPG
FILTRE A AIR PRINCIPAL RADIALSEAL
FILTRE A AIR SECURITE RADIALSEAL
CUVE FPG VAC 7"
| 1 | GEHL - 366001101200 (G070006) |
| 1 | GARDNER DENVER - SW25182 (G070006) |
| 1 | HAULOTTE - 2326006790 (G070006) |
| 1 | HAVAM - HD2910 (G070006) |
| 1 | A P PARTS - 3202360 (G070006) |
| 1 | HANOMAG TRAKTOREN - 4240171M92 (G070006) |
| 1 | HANOMAG TRAKTOREN - 42U0113110 (G070006) |
| 1 | HYSTER - S00762460002 (G070006) |
| 1 | HYSTER - S00762462 (G070006) |
| 1 | KALMAR - 9214240057 (G070006) |
| 1 | KOMATSU - 848001070 (G070006) |
| 1 | KOMATSU - Z760270006 (G070006) |
| 1 | LISSMAC - 206642 (G070006) |
| 1 | LOESING - 020022 (G070006) |
| 1 | LOMBARDINI - 10437003850 (G070006) |
| 1 | MECANO CONTINENTAL - 40346000 (G070006) |
| 1 | MECALAC - 6050175 (G070006) |
| 1 | MASSEY FERGUSON - 3543545M91 (G070006) |
| 1 | MOFFET - 620147 (G070006) |
| 1 | AUSA - 430121000 (G070006) |
| 1 | MERLO - 69846 (G070006) |
| 1 | MOUVEX - 223199 (G070006) |
| 1 | MOUVEX - 31265900 (G070006) |
| 1 | NEW HOLLAND - 85805390 (G070006) |
| 1 | ORENSTEIN & KOPPEL - 2479829 (G070006) |
| 1 | PALAZZANI INDUSTRIE - 14140067 (G070006) |
| 1 | REGGIANE CRANES - 2470147001 (G070006) |
| 1 | SAME - 242496100 (G070006) |
| 1 | SDMO - 30801032301 (G070006) |
| 1 | THWAITES - 15335 (G070006) |
| 1 | TIM - 1226616 (G070006) |
| 1 | TAMROCK - 55020458 (G070006) |
| 1 | TUMOSAN - 7254827 (G070006) |
| 1 | BELLE ENGINEERING - 210017 (G070006) |
| 1 | TEREX - 2479829 (G070006) |
| 1 | WEIDEMANN - 5747070006 (G070006) |
| 1 | ATLAS WEYHAUSEN - 8017305 (G070006) |
| 1 | ATLAS WEYHAUSEN - 8018305 (G070006) |
| 1 | WALGAHN-MOTORENTECHN - 00810094 (G070006) |
| 1 | WALGAHN-MOTORENTECHN - 810094 (G070006) |
| 1 | WORDSWORTH HOLDINGS PLC - SX621224 (G070006) |
| 1 | ZETOR - 71011291 (G070006) |
| 1 | LOESING - 20022 (G070006) |
| 1 | MECANO CONTINENTAL - 40346 (G070006) |
| 1 | MOUVEX - 312659 (G070006) |
| 1 | WACKER NEUSON - 1000199475 (G070006) |
| 1 | CATERPILLAR - 2652C111 (G070006) |
| 1 | PERKINS - 2652C111 (G070006) |
| 1 | PERKINS - 2652C112 (G070006) |
| 1 | CASE/CASE IH - 47128199 (G070006) |
| 1 | CATERPILLAR - 1226616 (G070006) |
| 1 | ATLANTIS DIESEL ENGINES - D138AE36414 (G070006) |
| 1 | CLARK,J.L. - M669341 (G070006) |
| 1 | CUMMINS - CDD000642 (G070006) |
| 1 | DONALDSON - FPG070006 (G070006) |
