Technical Data:
Outer Diameter: 102 MM
Thread Size: 1-12 UN
Length: 150 MM
Gasket OD: 99 MM
Gasket ID: 88 MM
Efficiency 50%: 17 MICRON
Efficiency 95%: 27 MICRON
Efficiency 99%: 39 MICRON
Efficiency Test Std: ISO 4548-12
Anti-Drainback Valve: Yes
Bypass Valve: Yes
Bypass Valve Setting LR: 0.8 BAR
Bypass Valve Setting HR: 1 BAR
Media Type: Cellulose
Collapse Burst: 6.9 BAR
Type: Full-Flow
Style: Spin-On
Primary Application: MITSUBISHI 32B4020100
Accessories:
| 1 | IHI - OE14 (P502476) |
| 1 | MITSUBISHI - 32B4000100 (P502476) |
| 1 | MITSUBISHI - 32B4020100 (P502476) |
| 1 | M.D.F. SARL - MDL6002 (P502476) |
| 1 | JUNGHEINRICH - 14368310 (P502476) |
| 1 | CATERPILLAR - 1146853 (P502476) |
| 1 | CATERPILLAR - 32B4020100 (P502476) |
| 1 | LUBER-FINER - LFP5748 (P502476) |
| 1 | MANN & HUMMEL - W1135 (P502476) |
| 1 | NAPA - 7411 (P502476) |
| 1 | DONALDSON - J8613100 (P502476) |
| 1 | SAKURA - C5812 (P502476) |
| 1 | SURE FILTER - SFO3100 (P502476) |
| 1 | WIX - 57411 (P502476) |
| 1 | HIFI FILTER / JURA FILTRATION - SO6080 (P502476) |
| 1 | SF-FILTER - SP5145 (P502476) |
| 1 | BALDWIN - B40054 (P502476) |
| 1 | FLEETGUARD - LF17507 (P502476) |
| 1 | CARQUEST - 84411 (P502476) |
