Technical Data:
Inlet Diameter: 63.88 MM
Outlet Diameter: 63.88 MM
Body Diameter Maximum: 167.6 MM
Body Length: 495.3 MM
Overall Length: 558.8 MM
Rated Flow LR: 11.7 CMM
Rated Flow MR: 16.6 CMM
Rated Flow HR: 20.3 CMM
Back Pressure Low-Range: 25 MM HG
Back Pressure Mid-Range: 51 MM HG
Back Pressure High-Range: 76 MM HG
Attenuation LR: 15 DBA
Attenuation HR: 20 DBA
Inlet Clock Position: 6:00
Outlet Clock Position: 12:00
Style: Style 5
Accessories:
| 1 | GRIMMER SCHMIDT - 12466144 (M065073) |
| 1 | HEAVY DUTY MFG - 31242 (M065073) |
| 1 | HURRICANE COMPRESSOR - 12470842 (M065073) |
| 1 | INGERSOLL RAND - 46634150 (M065073) |
| 1 | INGERSOLL RAND - RM46634150 (M065073) |
| 1 | INGERSOLL RAND - RM4664150 (M065073) |
| 1 | JLG - 10837799 (M065073) |
| 1 | LULL - 10837799 (M065073) |
| 1 | LULL - 37799X (M065073) |
| 1 | INTERNATIONAL - DCM065073 (M065073) |
| 1 | TRAK INTERNATIONAL - 8275035 (M065073) |
| 1 | TAYLOR - 2403783 (M065073) |
| 1 | INGERSOLL RAND - 43846716 (M065073) |
| 1 | CASE/CASE IH - NM065073 (M065073) |
| 1 | CLARK - 2797478 (M065073) |
