Technical Data:
Inlet Diameter: 89.28 MM
Outlet Diameter: 89.28 MM
Body Diameter Maximum: 228.6 MM
Body Length: 552.4 MM
Overall Length: 736.6 MM
Rated Flow LR: 24.5 CMM
Rated Flow MR: 34 CMM
Rated Flow HR: 43.2 CMM
Back Pressure Low-Range: 25 MM HG
Back Pressure Mid-Range: 51 MM HG
Back Pressure High-Range: 76 MM HG
Attenuation LR: 12 DBA
Attenuation HR: 18 DBA
Style: Style 1
Accessories:
| 1 | GROVE - 7642000012 (M091046) |
| 1 | LETOURNEAU - 0868829 (M091046) |
| 1 | NELSON - 201565N (M091046) |
| 1 | VERMEER - 296277847 (M091046) |
