Technical Data:
Inlet Diameter: 127.64 MM
Outlet Diameter: 127.64 MM
Body Diameter Maximum: 227.84 MM
Body Length: 508 MM
Overall Length: 673 MM
Rated Flow LR: 40.5 CMM
Rated Flow MR: 57.3 CMM
Rated Flow HR: 70.1 CMM
Back Pressure Low-Range: 25 MM HG
Back Pressure Mid-Range: 51 MM HG
Back Pressure High-Range: 76 MM HG
Attenuation LR: 10 DBA
Attenuation HR: 15 DBA
Style: Style 1
Accessories:
| 1 | ALLMAND BROS - ME458M (M090595) |
| 1 | EAGLE TRUCK PRODUCTS - E117 (M090595) |
| 1 | FORD - 9575M090595 (M090595) |
| 1 | FREIGHTLINER - DNM090595 (M090595) |
| 1 | AP EXHAUST PRODUCTS INC - 3895 (M090595) |
| 1 | HEAVY DUTY MFG - 31253 (M090595) |
| 1 | A P PARTS - 3895 (M090595) |
| 1 | ASTEC UNDERGROUND - 3014052056 (M090595) |
| 1 | MACK - 2191M090595 (M090595) |
| 1 | INTERNATIONAL - DCM090595 (M090595) |
| 1 | NELSON - 200238N (M090595) |
| 1 | SULLIVAN PALATEK - 05018750029 (M090595) |
| 1 | SULLIVAN PALATEK - 050187850029 (M090595) |
| 1 | SULLIVAN PALATEK - 1878529 (M090595) |
| 1 | SULLIVAN PALATEK - 501878529 (M090595) |
| 1 | STEMCO - 1901336 (M090595) |
| 1 | STEMCO - 1901383 (M090595) |
| 1 | TRUCKEX - 3895 (M090595) |
| 1 | VERMEER - 180005348 (M090595) |
| 1 | WALKER MANUFACTURING - 22771 (M090595) |
| 1 | WALKER MANUFACTURING - 22964 (M090595) |
| 1 | CAMECO - CB01476929 (M090595) |
| 1 | DART - MFM090595 (M090595) |
| 1 | DYNAFLEX - 87500674 (M090595) |
| 1 | DYNAFLEX - 87500674Q (M090595) |
| 1 | FLXIBLE - 87309100001 (M090595) |
| 1 | GRAND ROCK - M595 (M090595) |
| 1 | PARTS DISTRIBUTING - SM5590 (M090595) |
