Technical Data:
Inlet Diameter: 76.66 MM Outlet Diameter: 76.66 MM Body Diameter Maximum: 215 MM Body Length: 501.6 MM Overall Length: 616.4 MM Rated Flow LR: 18 CMM Rated Flow MR: 25 CMM Rated Flow HR: 31.86 CMM Back Pressure Low-Range: 25 MM HG Back Pressure Mid-Range: 51 MM HG Back Pressure High-Range: 76 MM HG Attenuation LR: 12 DBA Attenuation HR: 18 DBA Inlet Clock Position: 6:00 Outlet Clock Position: 12:00 Style: Style 5
