Technical Data:
Inlet Diameter: 76.66 MM
Outlet Diameter: 76.6 MM
Body Diameter Maximum: 215 MM
Body Length: 666.8 MM
Overall Length: 749.3 MM
Rated Flow LR: 13.2 CMM
Rated Flow MR: 18.6 CMM
Rated Flow HR: 22.7 CMM
Back Pressure Low-Range: 25 MM HG
Back Pressure Mid-Range: 51 MM HG
Back Pressure High-Range: 76 MM HG
Attenuation LR: 15 DBA
Attenuation HR: 20 DBA
Inlet Clock Position: 3:00
Outlet Clock Position: 6:00
Style: Style 3
Accessories:
| 1 | FORD - 9575M085090 (M085090) |
| 1 | FREIGHTLINER - DNM085090 (M085090) |
| 1 | GENERAC - 0D8473 (M085090) |
| 1 | GENERAC - OD8473 (M085090) |
| 1 | GENERAC - OD8473R (M085090) |
| 1 | AP EXHAUST PRODUCTS INC - 3626 (M085090) |
| 1 | GRADALL - 1755012 (M085090) |
| 1 | GROVE - 7642000029 (M085090) |
| 1 | HAVAM - 00008223 (M085090) |
| 1 | HEAVY DUTY MFG - 31102 (M085090) |
| 1 | A P PARTS - 3626 (M085090) |
| 1 | A P PARTS - 3626Q (M085090) |
| 1 | INGERSOLL RAND - 22320253 (M085090) |
| 1 | INGERSOLL RAND - 35576271 (M085090) |
| 1 | INGERSOLL RAND - 50901719 (M085090) |
| 1 | INGERSOLL RAND - 59189100 (M085090) |
| 1 | ISUZU - X14152005 (M085090) |
| 1 | KOEHRING - 125695 (M085090) |
| 1 | KOHLER - 253237 (M085090) |
| 1 | KOMATSU - 1243327H1 (M085090) |
| 1 | ASTEC UNDERGROUND - 304605097 (M085090) |
| 1 | LEROI - 78318 (M085090) |
| 1 | LEROI - 783181 (M085090) |
| 1 | LEROI - GD1755012 (M085090) |
| 1 | MORBARK - 29323072 (M085090) |
| 1 | BADGER - 76080439 (M085090) |
| 1 | BARKO HYDRAULICS - 53501016 (M085090) |
| 1 | INTERNATIONAL - DCM085090 (M085090) |
| 1 | NELSON - 86192M (M085090) |
| 1 | OSHKOSH - 3HS880 (M085090) |
| 1 | OSHKOSH - P109398 (M085090) |
| 1 | P & H - 27Q686 (M085090) |
| 1 | PANDROL JACKSON - 2511251 (M085090) |
| 1 | PETTIBONE - 0RO23180076 (M085090) |
| 1 | PETTIBONE - 44045 (M085090) |
| 1 | PETTIBONE - 53501016 (M085090) |
| 1 | PETTIBONE - R02318076 (M085090) |
| 1 | ROSCO - 36790 (M085090) |
| 1 | RAYGO - 0980240 (M085090) |
| 1 | RAYGO - 1207032 (M085090) |
| 1 | RAYGO - 1207032A (M085090) |
| 1 | RAYGO - 980240 (M085090) |
| 1 | SELLICK EQPT LTD - 190699 (M085090) |
| 1 | STEMCO - 1901332 (M085090) |
| 1 | TAYLOR - 1007537 (M085090) |
| 1 | VERMEER - 116370001 (M085090) |
| 1 | VERMEER - 1163700011 (M085090) |
| 1 | WALDON - 414714 (M085090) |
| 1 | WALKER MANUFACTURING - 22767 (M085090) |
| 1 | WALGAHN-MOTORENTECHN - 00810300 (M085090) |
| 1 | WALGAHN-MOTORENTECHN - 810300 (M085090) |
| 1 | B R LEE INDUSTRIES - 36790 (M085090) |
| 1 | BRODERSON - 060094217 (M085090) |
| 1 | BRODERSON - 60094217 (M085090) |
| 1 | HAVAM - 8223 (M085090) |
| 1 | CATERPILLAR - 0980240 (M085090) |
| 1 | CATERPILLAR - 980240 (M085090) |
| 1 | CETCO INCORPORATED - 1243327H1 (M085090) |
| 1 | CHARDONNET - 7408509000 (M085090) |
| 1 | CAMECO - 0550038023 (M085090) |
| 1 | CAMECO - 05538023 (M085090) |
| 1 | CAMECO - 550038023 (M085090) |
| 1 | CAMECO - 5538023 (M085090) |
| 1 | CMI - 400298000 (M085090) |
| 1 | CMI - 4002980000 (M085090) |
| 1 | CMI - 413224 (M085090) |
| 1 | CHAMPION ROAD - 205996 (M085090) |
| 1 | DYNAFLEX - 88H300102 (M085090) |
| 1 | DYNAFLEX - 88H300192 (M085090) |
| 1 | DRESSER - 1243327H1 (M085090) |
| 1 | MOBILE PRODUCTS INCORPORATED - 414714 (M085090) |
