Technical Data:
Inlet Diameter: 127.64 MM
Outlet Diameter: 127.64 MM
Body Diameter Minimum: 254 MM
Body Diameter Maximum: 381 MM
Body Length: 698.5 MM
Overall Length: 717.7 MM
Rated Flow LR: 38.4 CMM
Rated Flow MR: 54.3 CMM
Rated Flow HR: 66.5 CMM
Back Pressure Low-Range: 25 MM HG
Back Pressure Mid-Range: 51 MM HG
Back Pressure High-Range: 76 MM HG
Attenuation LR: 15 DBA
Attenuation HR: 20 DBA
Inlet Clock Position: 6:00
Outlet Clock Position: 12:00
Style: Style 6
Accessories:
| 1 | FORD - 9575M120418 (M120418) |
| 1 | AP EXHAUST PRODUCTS INC - 3941 (M120418) |
| 1 | HEAVY DUTY MFG - 31250 (M120418) |
| 1 | HOBART - EB5665 (M120418) |
| 1 | HOBART - EB5922 (M120418) |
| 1 | HURRICANE COMPRESSOR - 63229 (M120418) |
| 1 | ASTEC UNDERGROUND - 3018051102 (M120418) |
| 1 | INTERNATIONAL - DCM120418 (M120418) |
| 1 | OSHKOSH - P103952 (M120418) |
| 1 | RIKER - 15011 (M120418) |
| 1 | RIKER - 15911 (M120418) |
| 1 | STEMCO - 1901134 (M120418) |
| 1 | TRUCKEX - 3941 (M120418) |
| 1 | WALKER MANUFACTURING - 22452 (M120418) |
| 1 | CASE/CASE IH - NM120418 (M120418) |
| 1 | CMI - 004013195000 (M120418) |
| 1 | CMI - 4001319500 (M120418) |
| 1 | CMI - 4013195000 (M120418) |
| 1 | CMI - 413195 (M120418) |
| 1 | CUMMINS - 10000494 (M120418) |
